Freq.
(kHz) |
Call |
Power |
Description |
| 22.2 |
JJI |
500W |
海上自衛隊 |
えびの送信所 潜水艦通信用 |
| 11.904761 |
ALPHA
Radionavigation
System |
50 kW
to
100 kW |
Russian military naval |
ロシアのオメガ航法システム相当の双曲線航法システム
送信タイミング： 周期 3.6 秒、6 time slots at 0.4 sec. duration, 0.2 sec. spacing
送信局： Komsomolskamur, Novosibirsk, Krasnodar |
| 12.648809 |
| 14.880952 |
| 15.625 |
| 18.1 |
RDL |
(Unknown) |
Multiple stations share this frequency and call sign. The transmitters
are believed to be located at Krasnodar; Nizhniy Novgorod; Arkhangelsk;
Tashkent, Uzbekistan; Molodechno, Belarus; and Kalinigrad. |
| RLO |
The transmitter is believed to be located at Ryazan (also spelled Riazan
or R'azan), Russia. |
| RKS |
The transmitter is believed to be located at Murmansk, Russia. |
| 20.5 |
RJH63
RJH66
RJH69
RJH77
RJH99
RAB99
|
(Unknown) |
Six Russian TS stations transmit on this frequency at
different times. Their locations are as follows:
RJH63 Krasnodar,
Russia
RJH66 Bishkek, Kyrgyzstan
RJH69 Molodechno,
Belarus
RJH77 Arkhangelsk, Russia
RJH99 Nizhniy Novgorod,
Russia
RAB99 Nizhniy Novgorod, Russia (参考外部リンク：RAB99の詳細)
All these stations have the
nickname "Beta." |
| 23.0 |
| 25.0 |
| 25.1 |
| 25.5 |
| 18.9 |
RDL & RKS |
(Unknown) |
Multiple communication stations share this frequency. The transmitter locations
are unknown. |
| 21.1 |
RDL |
(Unknown) |
Several stations share this frequency and call sign. One is located in
Krasnodar Krai, Russia. Another is in Tashkent, Uzbekistan. The locations
of the others are unknown. |
| 27.3 |
RDL |
(Unknown) |
A Russian military headquarters communication station
believed to be located in far north-eastern Russia. |
| |
|
|
|
google：巨大なアンテナ施設が見える、 |
|
|
|
|
| 17.9 |
(None, but nicknamed "Channel One") |
(Unknown) |
U.S. Navy
TACAMO
(Take Charge and Move Out)
mobile communication stations.
|
The transmitter locations are unknown and subject to change.
TACAMO(Take Charge And Move Out)機（空中通信中継機）
参考外部リンク：OLD TACAMO、 TACAM (U.S. Navy）、
・核戦争に備えるために開発されたシステム
・航空機E-6マーキュリーから VLF通信時 1,220mおよび7,925mの長大なアンテナを空中に垂らし、それを垂直に保つために旋回を続ける。 |
|
| 18.0 |
(None) |
| 23.1 |
| 25.7 |
NOV |
| 26.9 |
| 27.0 |
| 27.2 |
| 27.5 |
| 27.7 |
| 27.6 |
serving the Atlantic Ocean. |
| 29.3 |
| 27.9 |
serving the Pacific Ocean. |
| 29.4 |
| 29.6 |
worldwide. |
| 19.8 |
NWC |
1000 KW |
U.S. Navy |
オーストラリアの米軍局NWCからの信号を確認できる。(19.8kHz: MSK変調によりスペクトルが広がっている。)
Harold E. Holt at Exmouth, Australia. operated by the Royal Australian
Navy. |
| 21.4 |
NPM |
566 KW |
located at Laualualei, Oahu, Hawaii. |
| 24.0 |
NAA |
1000 KW |
at Cutler, Maine.
This station is part of the NATO Interoperable Submarine Broadcast System. |
| 24.8 |
NLK |
250 KW |
located at Jim Creek, Washington.
It uses a Continental Electronics Corp. transmitter and a horizontal wire
transmitting antenna strung between two mountain tops. |
| 25.2 |
NML |
500 KW |
located at LaMour, North Dakota.
This station is part of the NATO Interoperable Submarine Broadcast System. |
| ( 21.4 ) |
NSS |
400 kW |
Washington USA |
| ( 28.5 ) |
NAU |
100 kW |
Aguada Puerto Rico |
| |
FTA |
|
Assise France |
| ( 16.0 ) |
GBR |
750 kW |
Rugby UK |
| 13.0 |
(None) |
(Unknown) |
Royal Australian Navy |
located at Gippsland, Woodside, Victoria, Australia (on Victoria's south-eastern
coast). The transmitting antenna is 1040 feet (427 meters) high
and is the highest VLF antenna in the world. |
|
|
|
|
| 17.2 |
SAQ |
(Unknown) |
Grimeton Radio in Varberg, Sweden. Only operates
sporadically. |
| 18.2 |
VTX |
(Unknown) |
Indian Navy |
located at South Vijayanarayanam village, 18.64 miles (30 km) south of
Turunelveli on the Kanyakumari highway, in India. |
| 18.3 |
HWU |
(Unknown) |
French Navy |
located at Le Blanc, France. |
| 20.9 |
HWU |
500 KW |
located in Rosnay, France. |
| 21.05 |
HWU |
(Unknown) |
| 21.75 |
HWU |
(Unknown) |
located at Le Blanc, France. |
| 16.4 |
JXN |
(Unknown) |
NATO naval |
located at Novik, Norway. It is operated by NODECA and is also used by the Norwegian Navy. |
| 20.27 |
ICV |
(Unknown) |
NATO naval |
located at Isola di Tavolara, Sardegna, Italy. |
| 23.4 |
DHO38 |
(Unknown) |
Operated for NATO by Bundesmarine, the German Navy, which
likely also uses it for German submarine communications. Located at Rhauderfehn,
Germany. |
| 19.6 |
GBZ |
(Unknown) |
British |
located near Anthorn, Combria, in the north-west region of England.
The station is operated by VT Communications (part of VT Group plc.) under contract with the
Royal Navy. |
| 20.0 |
VLF |
6 KW transmiiter power
500 Watts ERP |
A VLF beacon station located near the South Pole in Antarctica that is
operated by Stanford University. The transmitting antenna is a 4.35 mile
(7 km) horizontal wire dipole 4 to 5 feet above the ice. It transmits one-minute
duration beacon signals at 15-minute intervals. (参考外部リンク： More information） |
| 20.6 |
3SA |
(Unknown) |
A Chinese Navy communication station located at Changde in the Peoples
Republic of China. The frequency is shared with 3SB 3SA and transmission
typically alternate between the two stations. |
| 20.6 |
3SB |
(Unknown) |
| 25.0 |
PWB |
(Unknown) |
Brazilian Navy |
Belem Radio. located in Belem, Brazil. |
| 26.6 |
CAA2A |
(Unknown) |
Chilean Navy |
located at Santiago, Chile. |
| 26.7 |
TBB |
(Unknown) |
Turkish Navy |
located at Bafa, Republic of Turkey (Turkiye). |
| 30.00 |
PWI |
(Unknown) |
Brazilian Navy |
located at Recife, Brazil. |
